Canon IXUS 160 Specifications
IMAGE SENSOR
Type
1/2.3 type CCD
Effective Pixels
Approx. 20.0M¹
Effective / Total Pixels
Approx. 20.5M
Colour Filter Type
Primary Colour
IMAGE PROCESSOR
Type
DIGIC 4+ with iSAPS technology
LENS
Focal Length
5.0 – 40.0 mm (35 mm equivalent: 28 – 224 mm)
Zoom
Optical 8x
ZoomPlus 16x
Digital Approx. 4x
Combined Approx. 32x¹
Maximum f/number
f/3.2 – f/6.9
Construction
8 elements in 7 groups
(1 double-sided aspherical lens)
Image Stabilisation
Digital (Digital IS Mode)
FOCUSING
Type
TTL
AF System/ Points
AiAF (Face Detection / 9-point), 1-point AF (fixed to centre)
AF Modes
Single, Continuous (Auto mode only), Servo AF/AE, Tracking AF¹
AF POINT SELECTION
AF Lock
Yes
AF Assist Beam
Yes
FOCUS BRACKETING
Closest Focusing Distance
1 cm (W) from front of lens in Macro
EXPOSURE CONTROL
Metering modes
Evaluative (linked to Face Detection AF frame), Centre-weighted average, Spot (centre)
AE Lock
Yes
Exposure Compensation
+/- 2 EV in 1/3 stop increments.
Enhanced i-Contrast for automatic dynamic range correction
AEB
ISO sensitivity
AUTO, 100, 200, 400, 800, 1600
SHUTTER
Speed
1 – 1/2000 sec. (factory default)
15 – 1/2000 sec. (total range – varies by shooting mode)
WHITE BALANCE
Type
TTL
Settings
Auto (including Face Detection WB), Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H, Custom
COLOUR MATRIX
Type
sRGB
LCD MONITOR
Monitor
6.8 cm (2.7") LCD (TFT), Approx. 230,000 dots
Coverage
Approx. 100%
Brightness
Adjustable to one of five levels. Quick-bright LCD
FLASH
Modes
Auto, Manual Flash On / Off, Slow Synchro
Slow Sync Speed
Yes. Fastest speed 1/2000 sec.
Red-Eye Reduction
Yes
Flash Exposure Compensation
Face Detection FE, Smart Flash Exposure
Flash Exposure Lock
Yes
SECOND CURTAIN SYNCHRONISATION
Built-in Flash Range
50 cm – 3.0 m (W) / 1.3 – 1.5 m (T)
External Flash
Canon High Power Flash HF-DC1
Canon High Power Flash HF-DC2
SHOOTING
Modes
Smart Auto (32 scenes detected), P, Portrait, Live View Control, FaceSelf-Timer, Low Light (5.0 MP), Digital IS, Fish-eye Effect, Miniature Effect, Toy Camera Effect, Monochrome, Super Vivid, Poster Effect, Snow, Fireworks, Long Shutter
Modes in Movie
Smart Auto (21 scenes detected), P, Portrait, Miniature Effect, Monochrome, Super Vivid, Poster Effect, Snow, Fireworks
PHOTO EFFECTS
Drive modes
Single, Continuous, Self-Timer
Continuous Shooting
Approx. 0.8 shots/sec. (until memory card becomes full)¹²
RECORDING PIXELS / COMPRESSION
Image Size
4:3 - (L) 5152 x 3864, (M1) 3648 x 2736, (M2) 2048 x 1536, (S) 640 x 480, (W) 5152 x 2896
Resize in playback (M2, S)
Compression
Fine
Movies
(HD) 1280 x 720, 25 fps, (L) 640 x 480, 30 fps
Miniature Effect (HD) 5 fps, 2.5 fps, 1.25 fps
Miniature Effect (L) 6 fps, 3 fps, 1.5 fps
Movie Length
(HD) Up to 4 GB or 29 min. 59 sec.¹
(L) up to 4 GB or 1 hour²
FILE TYPES
Still Image Type
JPEG compression, (Exif 2.3 [Exif Print] compliant) / Design rule for Camera File system, Digital Print Order Format [DPOF] Version 1.1 compliant
Movies
MOV [Video:MPEG-4 AVC / H.264, Audio: Linear PCM (monaural)]
DIRECT PRINT
Canon Printers
Canon SELPHY Compact Photo Printers and Canon Inkjet Printers supporting PictBridge
PictBridge
Yes
GPS
Red-Eye Correction
Yes, during shooting and playback
MY CATEGORY
Intelligent Orientation Sensor
Yes, with Auto Rotate
HISTOGRAM
Playback zoom
Approx. 2x – 10x
Self Timer
Approx. 2 or 10 sec. or Custom
Menu Languages
English, German, French, Dutch, Danish, Finnish, Italian, Norwegian, Swedish, Spanish, Simplified Chinese, Chinese (traditional), Japanese, Russian, Portuguese, Korean, Greek, Polish, Czech, Hungarian, Turkish, Thai, Arabic, Ukrainian, Romanian, Farsi, Malaysian, Hindi, Indonesian, Vietnamese, Hebrew
INTERFACE
Computer
Hi-Speed USB (MTP, PTP) dedicated connector (Mini-B compatible)
Other
A/V output, dedicated connector (PAL/NTSC)
MEMORY CARD
Type
SD, SDHC, SDXC
SUPPORTED OPERATING SYSTEM
PC & Macintosh
Windows 8 / 8.1 / 7 SP1
Mac OS X 10.8 / 10.9 / 10.10
POWER SOURCE
Batteries
Rechargeable Li-ion Battery NB-11L/ NB-11LH (NB-11L battery and charger supplied)
Battery life
Approx. 220 shots
Eco Mode: Approx. 300 shots
Approx. 240min. playback
A/C Power Supply
Optional, AC Adapter Kit ACK-DC90
ACCESSORIES
Cases / Straps
Soft Case DCC-1370
Soft Case DCC-1350
Soft Case DCC-1320
WATERPROOF / WEATHERPROOF CASE
Flash
Canon High Power Flash HF-DC1
Canon High Power Flash HF-DC2
Power Supply & Battery Chargers
AC Adapter Kit ACK-DC90, Battery Charger CB-2LFE / CB-2LDE
Other
Canon AV Cable AVC-DC400
Interface cable IFC-400PCU
PHYSICAL SPECIFICATIONS
Operating Environment
0 – 40 °C, 10 – 90% humidity
Dimensions (WxHxD)
95.2 x 54.3 x 22.1 mm
Weight
Approx. 127 g (including battery and memory card)
Disclaimer
All data is based on Canon standard testing methods (according to CIPA Standards) except where indicated.
Subject to change without notice.
All data is based on Canon standard testing methods (according to CIPA Standards) except where indicated.
Subject to change without notice.
All data is based on Canon standard testing methods (according to CIPA Standards) except where indicated.
Subject to change without notice.
Footnote
¹ Image processing may cause a decrease in the number of pixels.
¹ Depending on the image size selected.
¹ Some settings limit availability.
¹ Under conditions where the flash does not fire.
² Depending on memory card speed / capacity / compression setting.
¹ The following Speed Class memory cards are required for maximum record time: (HD) 1280 x 720 Speed Class 4 or above. (Full HD) 1920 x 1080 Speed Class 6 or above. (iFrame) 1280 x 720 Speed Class 6 or above.
² Depending on memory card speed / capacity / compression setting.
¹ Image processing may cause a decrease in the number of pixels.
¹ Depending on the image size selected.
¹ Some settings limit availability.
¹ Under conditions where the flash does not fire.
² Depending on memory card speed / capacity / compression setting.
¹ The following Speed Class memory cards are required for maximum record time: (HD) 1280 x 720 Speed Class 4 or above. (Full HD) 1920 x 1080 Speed Class 6 or above. (iFrame) 1280 x 720 Speed Class 6 or above.
² Depending on memory card speed / capacity / compression setting.
¹ Image processing may cause a decrease in the number of pixels.
¹ Depending on the image size selected.
¹ Some settings limit availability.
¹ Under conditions where the flash does not fire.
² Depending on memory card speed / capacity / compression setting.
¹ The following Speed Class memory cards are required for maximum record time: (HD) 1280 x 720 Speed Class 4 or above. (Full HD) 1920 x 1080 Speed Class 6 or above. (iFrame) 1280 x 720 Speed Class 6 or above.
² Depending on memory card speed / capacity / compression setting.
