IMAGE SENSOR
Type
1/1.7 type high-sensitivity CCD
Effective Pixels
Approx. 10.1M
ASPECT RATIO
Colour Filter Type
Primary Colour
IMAGE PROCESSOR
Type
DIGIC 5 with iSAPS technology
LENS
Focal Length
5.2 – 26.0 mm (35 mm equivalent: 24 – 120 mm)
Zoom
Optical 5x
ZoomPlus 9x
Digital Approx. 4x (with Digital Tele-Converter Approx. 1.4x or 1.8x¹)
Combined Approx. 20x
Maximum f/number
f/2.0-f/5.9
Construction
7 elements in 6 groups (1 double-sided aspherical lens, 1 double-sided aspherical UA lens and 1 single-sided aspherical lens)
Image Stabilisation
Yes (lens shift-type), approx. 3-stop¹. Intelligent IS
FOCUSING
Type
TTL
AF System/ Points
AiAF (9-point or Face Detection with Face Select and Track), 1-point AF (any position is available or fixed centre)
AF Modes
Single, Continuous, Servo AF/AE¹, Tracking AF
AF Point Selection
Size (Normal, Small)
AF Lock
Yes
AF Assist Beam
Yes
Manual Focus
Yes
FOCUS BRACKETING
Closest Focusing Distance
3 cm (W) from front of lens in macro
EXPOSURE CONTROL
Metering modes
Evaluative (linked to Face Detection AF frame), Centre-weighted average, Spot (centre or linked to Face Detection AF or FlexiZone AF frame)
AE Lock
Yes
Exposure Compensation
+/- 2 EV in 1/3 stop increments.
Enhanced i-Contrast for automatic dynamic range correction
AEB
ISO sensitivity
AUTO, 80, 100, 200, 400, 800, 1600, 3200, 6400
SHUTTER
Speed
1 – 1/2000 sec. (factory default)
15 – 1/2000 sec. (total range – varies by shooting mode)
WHITE BALANCE
Type
TTL
Settings
Auto (including Face Detection WB), Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H, Custom
COLOUR MATRIX
Type
sRGB
LCD MONITOR
Monitor
7.5 cm (3.0”) PureColor II G LCD (TFT). Approx. 461,000 dots
Coverage
Approx. 100%
Brightness
Adjustable to one of five levels. Quick-bright LCD
FLASH
Modes
Auto, Manual Flash On / Off, Slow Synchro
Slow Sync Speed
Yes. Fastest speed 1/2000 sec.
Red-Eye Reduction
Yes
Flash Exposure Compensation
+/- 2 EV in 1/3 stop increments. Face Detection FE, Safety FE, Smart Flash Exposure
Flash Exposure Lock
Yes
Manual Power Adjustment
3 levels with internal flash
Second Curtain Synchronisation
Yes
Built-in Flash Range
50 cm – 7.0 m (W) / 50 cm – 2.3 m (T)
External Flash
Canon High Power Flash HF-DC2
SHOOTING
Modes
Smart Auto (36 scenes detected), Program AE, Shutter priority AE, Aperture priority AE, Manual, Live View Control, SCN (Portrait, Smooth Skin, Smart Shutter (Smile, Wink Self-Timer, FaceSelf-Timer), High-speed Burst (2.5 MP), Stitch Assist, Snow, Fireworks), Creative Filters (Fish-eye Effect, Miniature Effect, Toy Camera Effect, Soft Focus, Monochrome, Super Vivid, Poster Effect, Color Accent, Color Swap)
Modes in Movie
Smart Auto (21 scenes detected), Program AE, Portrait, Miniature Effect, Monochrome, Super Vivid, Poster Effect, Snow, Fireworks, Color Accent, Color Swap
Photo Effects
My Colors (My Colors Off, Vivid, Neutral, Sepia, Black & White, Positive Film, Lighter Skin Tone, Darker Skin Tone, Vivid Blue, Vivid Green, Vivid Red, Custom Color)
Drive modes
Single, Continuous, Continuous with AF, Self-Timer
Continuous Shooting
Approx. 1.9 shots/sec
High-speed Burst (2.5MP): 4.5 shots/sec
with AF: Approx. 0.8 shots/sec
with Live View: Approx. 0.8 shots/sec
(all speeds are until memory card becomes full)¹²
RECORDING PIXELS / COMPRESSION
Image Size
4:3 - (L) 3648 x 2736, (M1) 2816 x 2112, (M2) 1600 x 1200, (S) 640 x 480
16:9 - (L) 3648 x 2048, (M1) 2816 x 1584, (M2) 1920 x 1080, (S) 640 x 360
3:2 - (L) 3648 x 2432, (M1) 2816 x 1880, (M2) 1600 x 1064, (S) 640 x 424
1:1 - (L) 2736 x 2736, (M1) 2112 x 2112, (M2) 1200 x 1200, (S) 480 x 480
Resize in playback (M2, S)
Compression
Superfine, Fine
Movies
(HD) 1280 x 720, 24 fps, (L) 640 x 480, 30 fps
Miniature Effect (HD) 4.8fps, 2.4fps, 1.2 fps, (L) 6fps, 3fps, 1.5fps
Movie Length
(HD) Up to 4 GB or 29 min. 59 sec.¹
(L and M) Up to 4 GB or 1 hour²
FILE TYPES
Still Image Type
JPEG compression, (Exif 2.3 [Exif Print] compliant) / Design rule for Camera File system, Digital Print Order Format [DPOF] Version 1.1 compliant
Movies
MOV [Video: H.264. Audio: Linear PCM (stereo)]
DIRECT PRINT
Canon Printers
Canon SELPHY Compact Photo Printers and Canon Inkjet Printers supporting PictBridge
PictBridge
Yes (via USB or Wireless LAN)
OTHER FEATURES
GPS
GPS via mobile (linked to compatible smartphone)
Red-Eye Correction
Yes, during shooting and playback
MY CATEGORY
Intelligent Orientation Sensor
Yes
Histogram
Yes
Playback zoom
Approx. 2x – 10x
Self Timer
Approx. 2 or 10 sec., Custom
Menu Languages
English, German, French, Dutch, Danish, Finnish, Italian, Greek, Norwegian, Portuguese, Russian, Swedish, Spanish, Ukrainian, Polish, Czech, Hungarian, Turkish, Simplified Chinese, Chinese (traditional), Japanese, Korean, Thai, Arabic, Romanian, Farsi, Hindi, Malay, Indonesian, Vietnamese
INTERFACE
Computer
Hi-Speed USB (MTP, PTP) dedicated connector (Mini-B compatible)
Other
HDMI Mini Connector (HDMI-CEC compatible) A/V output (PAL/NTSC)
Computer/Other
Wi-Fi (IEEE802.11 b/g/n), (2.4 GHz only)¹
MEMORY CARD
Type
SD, SDHC, SDXC
SUPPORTED OPERATING SYSTEM
PC & Macintosh
Windows 8/7 SP1/ Vista SP2/ XP SP3
Mac OS X v10.6 – 10.9
For Wireless LAN connection to a PC:
Windows 8/7 SP1
Mac OS X v10.6.8/10.7/10.8.2 or later
SOFTWARE
Browsing & Printing
ImageBrowser EX
OTHER
Image Manipulation
PhotoStitch, Map Utility
POWER SOURCE
Batteries
Rechargeable Li-ion Battery NB-6LH (battery and charger supplied)
Battery life
Approx. 200 shots
Eco mode approx. 300 shots
Approx. 300 min. playback
A/C Power Supply
Optional, AC Adapter Kit ACK-DC40
ACCESSORIES
Cases / Straps
Soft Case DCC-1450
Soft Case DCC-1920
Travel Case DCC-2500
LENSES
Flash
Canon High Power Flash HF-DC2
REMOTE CONTROLLER/ SWITCH
Power Supply & Battery Chargers
AC Adapter Kit ACK-DC40, Battery Charger CB-2LYE
Other
Canon HDMI Cable HTC-100, Interface cable IFC-400PCU
PHYSICAL SPECIFICATIONS
Operating Environment
0 – 40 °C, 10 – 90% humidity
Dimensions (WxHxD)
99.8 x 59.0 x 26.3 mm
Weight
Approx. 181 g (including battery/batteries and memory card)
Disclaimer
All data is based on Canon standard testing methods (according to CIPA Standards) except where indicated.
Subject to change without notice.
Footnote
¹ Depending on the image size selected.
¹ Values at maximum optical focal length. Cameras whose focal length exceeds 350mm (35mm equivalent) are measured at 350mm.
¹ Some settings limit availability.
¹ Some settings limit availability.
² Depending on memory card speed / capacity / compression setting.
¹ The following Speed Class memory cards are required for maximum record time: (HD) 1280 x 720 Speed Class 4 or above. (Full HD) 1920 x 1080 Speed Class 6 or above. (iFrame) 1280 x 720 Speed Class 6 or above.
² Depending on memory card speed / capacity / compression setting.
¹ Wi-Fi use may be restricted in certain countries or regions. Wi-Fi support varies by device and region. For more information visit www.canon-europe.com/wirelesscompacts
