IMAGE SENSOR
Type
1/2.3 type back-illuminated CMOS
Effective Pixels
Approx. 20.3M ¹
Effective / Total Pixels
Approx. 21.1M
Colour Filter Type
Primary Colour
IMAGE PROCESSOR
Type
DIGIC 6 with iSAPS technology
LENS
Focal Length
4.3 – 172.0 mm (35 mm equivalent: 24 – 960 mm)
Zoom
Optical 40x
Zoom
Plus 80x
Digital approx. 4.0x (with Digital Tele-Converter Approx. 1.6x or 2.0x¹)
Combined approx. 160x
Maximum f/number
f/3.3 – f/6.9
Construction
13 elements in 11 groups (1 Hi-UD lens, 3 UD lenses, 2 double-sided aspherical lenses, 1 single-sided aspherical lens)
Image Stabilisation
Yes (lens shift-type), Approx. 3.0-stop ¹. Intelligent IS plus 5-axis Advanced Dynamic IS
FOCUSING
Type
TTL
AF System/ Points
AiAF (Face Detection / 9-point), 1-point AF (fixed to centre)
AF Modes
Single, Continuous, Servo AF/AE ¹, Tracking AF,
AF Point Selection
Size (Normal, Small)
AF Lock
Yes
AF Assist Beam
Yes
Manual Focus
Yes, plus MF Peaking
Closest Focusing Distance
1 cm (W) from front of lens in Macro
EXPOSURE CONTROL
Metering modes
Evaluative (linked to Face Detection AF frame), Centre-weighted average, Spot (Centre)
AE Lock
Yes
Exposure Compensation
+/- 2 EV in 1/3 stop increments.
Enhanced i-Contrast for automatic dynamic range correction
ISO sensitivity
AUTO, 80, 100, 200, 400, 800, 1600, 3200
SHUTTER
Speed
1 – 1/3200 s (factory default)
15 – 1/3200 s (total range – varies by shooting mode)
WHITE BALANCE
Type
TTL
Settings
Auto (including Face Detection WB), Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H, Custom.
Multi-area WB correction available in Smart Auto
COLOUR MATRIX
VIEWFINDER
LCD MONITOR
Monitor
7.5 cm (3.0”) LCD (TFT), approx. 922,000 dots, sRGB colour reproduction
Coverage
Approx. 100%
Brightness
Adjustable to one of five levels. Quick-bright LCD
FLASH
Modes
Auto, Manual Flash On / Off, Slow Synchro
Slow Sync Speed
Yes. Fastest speed 1/2000 s
Red-Eye Reduction
Yes
Flash Exposure Compensation
+/- 2 EV in 1/3 stop increments. Face Detection FE, Safety FE, Smart Flash Exposure
Flash Exposure Lock
Yes
Manual Power Adjustment
3 levels with internal flash
Built-in Flash Range
50 cm – 4.0 m (W) / 2.0 m (T)
SHOOTING
Modes
Smart Auto (58 scenes detected), Hybrid Auto, Creative Shot, Program AE, Shutter priority AE, Aperture priority AE, Manual, Live View Control, Sports, SCN (Portrait, Smart Shutter (Smile, Wink Self-Timer, FaceSelf-Timer), Handheld Night Scene, Low Light (5.0 MP), Fireworks), Creative Filters (Fish-eye Effect, Miniature Effect, Toy Camera Effect, Monochrome, Soft Focus, Super Vivid, Poster Effect), Movie
Photo Effects
My Colors (My Colors Off, Vivid, Neutral, Sepia, Black & White, Positive Film, Lighter Skin Tone, Darker Skin Tone, Vivid Blue, Vivid Green, Vivid Red, Custom Color)
Drive modes
Single, Auto Drive, Continuous, Continuous with AF, Self-Timer
Continuous Shooting
Approx. 5.9 shots/s until memory card becomes full ¹
with AF: Approx. 4.6 shots/s² ³
with Live View: Approx.4.6 shots/s² ³
RECORDING PIXELS / COMPRESSION
Image Size
4:3 - (L) 5184 x 3888, (M1) 3648 x 2736, (M2) 2048 x 1536, (S) 640 x 480
16:9 - (L) 5184 x 2912, (M1) 3648 x 2048, (M2) 1920 x 1080, (S) 640 x 360
3:2 - (L) 5184 x 3456, (M1) 3648 x 2432, (M2) 2048 x 1368, (S) 640 x 424
1:1 - (L) 3888 x 3888, (M1) 2736 x 2736, (M2) 1536 x 1536, (S) 480 x 480
Resize option available in playback
Compression
Superfine, Fine
Movies
(Full HD) 1920 x 1080, 59.94 / 29.97 fps, (HD) 1280 x 720, 29.97 fps, (L) 640 x 480, 29.97 fps
Movie Length
(Full HD & HD) Up to 4 GB or 29 min 59 s ¹
(L) Up to 4 GB or 1 hour²
FILE TYPES
Still Image Type
JPEG compression, (Exif 2.3 [Exif Print] compliant) / Design rule for Camera File system, Digital Print Order Format [DPOF] Version 1.1 compliant
Movies
MP4 [Video: MPEG-4 AVC / H.264, Audio: MPEG-4 AAC-LC (stereo)]
DIRECT PRINT
Canon Printers
Canon SELPHY Compact Photo Printers and Canon Inkjet Printers supporting PictBridge
PictBridge
Yes (via USB or Wireless LAN)
OTHER FEATURES
GPS
GPS via mobile (via Canon Camera Connect app with compatible smart devices)
Red-Eye Correction
Yes, during shooting and playback
Intelligent Orientation Sensor
Yes, with Auto Rotate
Histogram
Yes, during playback
Playback zoom
Approx. 2x – 10x
Self Timer
Approx. 2, 10 s or Custom
Menu Languages
English, German, French, Dutch, Danish, Finnish, Italian, Greek, Norwegian, Portuguese, Russian, Swedish, Spanish, Ukrainian, Polish, Czech, Hungarian, Turkish, Simplified Chinese, Chinese (traditional), Japanese, Korean, Thai, Arabic, Romanian, Farsi, Hindi, Malay, Indonesian, Vietnamese, Hebrew
INTERFACE
Computer
Hi-Speed USB dedicated connector (Micro-B compatible)
Other
HDMI Micro (Type-D) Connector
Computer/Other
Wi-Fi (IEEE802.11b/g/n), (2.4 GHz only), with Dynamic NFC support ¹
MEMORY CARD
Type
SD, SDHC, SDXC (UHS Speed Class 1 compatible)
SUPPORTED OPERATING SYSTEM
PC & Macintosh
Windows 10 / 8.1 / 8 / 7 SP1 ¹
Mac OS X 10.9 / 10.10 / 10.11
For Wi-Fi connection to a PC:
Windows 10 / 8.1 / 8 / 7 SP1
Mac OS X 10.9 / 10.10
For Image Transfer Utility:
Windows 10 / 8.1 / 8 / 7 SP1
Mac OS X 10.9 / 10.10 / 10.11
SOFTWARE
Other
CameraWindow DC
Map Utility
Image Transfer Utility
Camera Connect app available on iOS and Android devices
POWER SOURCE
Batteries
Rechargeable Li-ion Battery NB-13L (battery and charger supplied)
Battery life
Approx. 250 shots
Eco Mode: Approx. 355 shots
Playback Mode: Approx. 300 min
A/C Power Supply
Charging via USB available with Compact Power Adapter CA-DC30E ¹ or other typical USB charging methods
ACCESSORIES
Cases / Straps
Soft Case DCC-1570
Travel Case DCC-2400
Travel Case DCC-2500
PowerShot Accessory Organizer
Power Supply & Battery Chargers
Compact Power Adapter CA-DC30E
Battery Charger CB-2LHE
Rechargeable Li-ion Battery NB-13L
Other
Interface cable IFC-600PCU
PHYSICAL SPECIFICATIONS
Operating Environment
0 – 40 °C, 10 – 90% humidity
Dimensions (WxHxD)
109.7 x 63.8 x 35.7 mm
Weight
Approx. 270 g (including battery and memory card)
Disclaimer
All data is based on Canon standard testing methods (according to CIPA Standards) except where indicated.
Subject to change without notice.
All data is based on Canon standard testing methods (according to CIPA Standards) except where indicated.
Subject to change without notice.
Footnote
¹ Image processing may cause a decrease in the number of pixels.
¹ Depending on the image size selected.
¹ Values at maximum optical focal length. Cameras whose focal length exceeds 350 mm (35 mm equivalent) are measured at 350 mm.
¹ Some settings limit availability.
¹ Sustained continuous shooting function requires compatible SDHC/SDXC UHS Speed Class 1 memory card, total number of frames captured varies depending on shooting subject.
² Under conditions where the flash does not fire.
³ Depending on memory card speed / capacity / compression setting.
¹ The following Speed Class memory cards are required for maximum record time: (HD) 1280 x 720 Speed Class 4 or above. (Full HD) 1920 x 1080 Speed Class 6 or above. (iFrame) 1280 x 720 Speed Class 6 or above.
² Depending on memory card speed / capacity / compression setting.
¹ Wi-Fi use may be restricted in certain countries or regions. Wi-Fi support varies by device and region. For more information visit www.canon-europe.com/wirelesscompacts
¹ Software applications compatible with Windows 10 in Windows 10 Desktop Mode only
¹ Charging via USB requires Interface Cable IFC-600PCU (Sold separately) or similar cable with USB Micro-B to USB type-A connectors. Charging time varies depending on the remaining battery power.
¹ Image processing may cause a decrease in the number of pixels.
¹ Depending on the image size selected.
¹ Values at maximum optical focal length. Cameras whose focal length exceeds 350 mm (35 mm equivalent) are measured at 350 mm.
¹ Some settings limit availability.
¹ Sustained continuous shooting function requires compatible SDHC/SDXC UHS Speed Class 1 memory card, total number of frames captured varies depending on shooting subject.
² Under conditions where the flash does not fire.
³ Depending on memory card speed / capacity / compression setting.
¹ The following Speed Class memory cards are required for maximum record time: (HD) 1280 x 720 Speed Class 4 or above. (Full HD) 1920 x 1080 Speed Class 6 or above. (iFrame) 1280 x 720 Speed Class 6 or above.
² Depending on memory card speed / capacity / compression setting.
¹ Wi-Fi use may be restricted in certain countries or regions. Wi-Fi support varies by device and region. For more information visit www.canon-europe.com/wirelesscompacts
¹ Software applications compatible with Windows 10 in Windows 10 Desktop Mode only
¹ Charging via USB requires Interface Cable IFC-600PCU (Sold separately) or similar cable with USB Micro-B to USB type-A connectors. Charging time varies depending on the remaining battery power.
