Canon XEED WUX500

XEED WUX500

Enjoy superior image quality and versatile connections with this WUXGA compact installation projector, which features LCOS technology, constant 5000 lumens brightness and a Canon quality 1.8x zoom lens plus HDBaseT and Wi-Fi.

XEED WUX500

Benefits

    • Achieve detailed, ultra-realistic images with native WUXGA resolution (1920 x 1200 pixels) and Full HD capability
    • Enjoy a vivid 5000 lumens constant* brightness and native 2000:1 contrast ratio
    • Create smooth, seamless images with vivid, accurate colours using LCOS panel and AISYS technology
    • 1.8x zoom lens with manual lens shift, zoom and focus for fast and accurate installation
    • Connect to a wide variety of devices thanks to HDBaseT connection** and Wi Fi for wireless LAN with Network Multi Projection (NMPJ)
    • Advanced imaging features include hardware edge blending, picture-by-picture and four corner keystone correction
    • PC-free multi projection via USB using up to nine projectors
    • HDMI and RJ-45 network ports
    • Easy access to the lamp and air filter helps keep maintenance costs down
    • Energy efficient with up to 5000h lamp life and only 30 dBA in ECO mode

Detailed Features

Take a look at a more detailed look into the Canon XEED WUX500

Compact, high-resolution installation projector


Enjoy superior image quality and versatile connections with the XEED WUX500 compact installation projector weighing only 5.6Kg. It delivers bright, detailed, high-resolution images from both computer and video-based sources, with easy to read text and smooth graphics thanks to the native WUXGA (1920 x 1200 pixels) resolution, which also supports Full HD.

Consistent* brightness


Canon's AISYS optical system delivers a powerful 5000 lumens brightness and a contrast ratio of 2000:1 for clear images, even in high ambient light levels. The 1.8x zoom lens has a constant F2.8 aperture, so the brightness is virtually unchanged regardless of zoom setting.

Advanced LCOS panel technology


The LCOS (Liquid Crystal On Silicon) panels work in combination with the AISYS system to create outstandingly smooth, seamless images with vivid, accurate colours, which are free from the unwanted 'lattice' and 'rainbow' effects that are often seen with other panel technologies.

Powerful imaging features put you in control


A range of advanced features gives you effortless flexibility and control over imaging. Built-in edge blending and registration adjustment let you seamlessly blend images from multiple projectors, while four-point keystone correction helps keep your image sharp and precise even when projecting at an angle. Picture-by-picture allows projection from two digital sources (or one digital and one analogue) ideal for video conferencing.

Simple brilliance


The projector's Canon quality 1.8x zoom lens delivers precise geometry, sharp focus and accuracy and is equipped with powered vertical and horizontal lens shift for superior installation flexibility.

Versatile connection options


Project still and moving images from a wide range of sources using an extensive choice of inputs. These include an HDBaseT connection** and Wi Fi, plus

Product Specification

Find out more about the Canon XEED WUX500, its features and what it can do.

For powerful brightness and a high contrast ratio

For powerful brightness and a high contrast ratio

Full HD video reproduced in perfect detail

Full HD video reproduced in perfect detail

HDMI Port

HDMI Port

Industry standard control protocol

Industry standard control protocol

HDBT

HDBT

Wi-Fi CERTIFIED

Wi-Fi Certified

Compatible HDBaseT Transmitters

(Other transmitters may be compatible but have not been tested)

Manufacturer Type Model Name Connection via HDBaseT Note
Video Audio LAN RS-232C
Crestron Transmitter DM-TX-201-C Yes Yes Yes No This TX does not have an RS-232C port.
DM-TX-401-C Yes Yes Yes No
Kramer Transmitter TP-581T Yes Yes Yes Yes
TP-582T Yes Yes Yes Yes
AMX Transmitter DX-TX Yes Yes Yes No This TX doesn’t support RS-232C for the projector.
Extron Transmitter XTP T USW 103 No No No No
Gefen Transmitter GEF-HDCAT5-ELRPOL(S) Yes Yes No*³ No This TX doesn’t support RS-232C for the projector.
Atlona Transmitter AT-HDTX-RSNET Yes*¹ Yes Yes No
CYP Transmitter PU-507-KIT Yes*¹ Yes Yes Yes

*¹ Might not display at the expected resolution when some input devices are connected
*² This projector doesn’t support “Extron XTP” feature.
*³ LAN communication is not possible while the projector is in Standby Mode (TX does not support LPPF2 mode)

Disclaimers
Default setting is LAN (Gbit).
Switching HDBaseT⇔LAN(Gbit), requires a restart of the projector.
