OPTICAL FEATURES/SPECIFICATIONS
Angle of view (horzntl, vertl, diagnl)
40º, 27º,46º
Lens construction (elements/groups)
6/5
No. of diaphragm blades
7
Minimum aperture
22¹
Closest focussing distance (m)
0.35
Maximum magnification (x)
0.21
Distance Information
Yes
AF actuator
STM
PHYSICAL SPECIFICATIONS
Filter diameter (mm)
49
Max. diameter x length (mm)
69.2 x 39.3
Weight (g)
160
ACCESSORIES
Lens cap
E-49
Lens hood
ES-68
Lens case/pouch
LP1014
Rear cap
Lens Dust Cap E
Magnification w/ Extension Tube EF12 II
0.45-0.24
Magnification w/ Extension Tube EF25 II
0.74-0.53
Extender Compatiblity
Not Compatible
SPECIFICATIONS WITH EF 1.4X III
SPECIFICATIONS WITH EF 2X III
Footnote
¹ Minimum aperture if using 1/3stop increments
¹ Minimum aperture if using 1/3stop increments
