OPTICAL FEATURES/SPECIFICATIONS
Image size
APS-C
35mm film equivalent focal length (mm)
24 - 72
Angle of view (horzntl, vertl, diagnl)
74°10′ - 28°20′
53°30′ - 19°05′
84°30′ - 33°40′
Lens construction (elements/groups)
10 elements / 9 groups
No. of diaphragm blades
7
Minimum aperture
22 - 40 (38)¹
Closest focussing distance (m)
0.25
Maximum magnification (x)
0.25 (at 45mm)
Distance Information
Yes
Image stabilizer
3.5-stops
AF actuator
STM
PHYSICAL SPECIFICATIONS
Dust/moisture resistance⁴
-
Filter diameter (mm)
49
Max. diameter x length (mm)
60.9 x 44.5¹
Weight (g)
130
ACCESSORIES
Lens cap
E-49
Lens hood
EW-53
Lens case/pouch
LP811
Rear cap
Lens Dust Cap EB
Magnification Extension Tube EF12 II
Not Compatible
Magnification Extension Tube EF25 II
Not Compatible
Extender Compatiblity
Not Compatible
Other Accessories
-
SPECIFICATIONS WITH EF 1.4X II
Focal Length
-
Maximum Aperture
-
Maximum Magnification
-
AF Possible
-
IS
-
SPECIFICATIONS WITH EF 2X II
Focal Length
-
Maximum Aperture
-
Maximum Magnification
-
AF Possible
-
IS
-
Footnote
¹ Dimension measured when lens is retracted
¹ Minimum aperture if using 1/3 stop increments
